Automatic Modular Type Fire Extinguishers

High Quality MODULAR TYPE MAP 90 POWDER

KANEX presents the modular type MAP powder (90%) UL listed Automatic fire extinguisher .It keeps guard, extinguishes fire quickly and efficiently when the Fire temperature reaches the temperature sensing bulb temperature. These modules are very useful especially in closed and remote places where fire could cause extensive damage if not detected and extinguished in time.

Available in Kg
Buy on Amazon

Available ranges of Temperature Sensing bulbs which sense Temperature are from 57 °C to 107 °C.

APPLICATION AREA

Special Features

High quality MAP 90% Powder UL listed.
Unique gauge testing system (UGTS) mechanism.
Brass chrome plated discharge sprinkler.
Tough Exterior and interior Coating with Pure Polyester (PP) powder.
Automatic Detection and Suppression in a single unit.
Extinguisher shells are 100% factory hydro tested to excess of 35 bar.
Expelling Agent UHP (Ultra High Pure) Grade Nitrogen.
Anti-corrosive Phosphate treated modules.
Provides securities in case of emergencies and power failure without power backup.
Easy as well more economical to maintain, service and re chargeable.
Bar Code labeling for better traceability.
Best available Fire ratings in its class with 5 years warranty.

TECHNICAL SPECIFICATIONS

MODEL KMPHQ-2-UL90% MODEL KMPHQ-2-UL90%
Capacity 2 kg Design Ceiling Mounted
Height (Approx.) 380 mm Diameter (Approx.) 150±10 mm
Average Discharge time 4-5 Sec. Hanging height above risk 2 m
Area Protection 1-1.5 m 2 Volume Protection 2.5 m 3
Average % Discharge 98% Operating Temperature -30 °C to +55 °C
Service/ Test Pressure 15 / 35 bar Expelling Agent Nitrogen (UHP Grade)
Full Weight (Approx.) 3.6 kg Empty Weight (Approx.) 1.6 kg
Shipping Weight (Approx.) 3.7 kg Mounting Bracket Ceiling mounting stand
Approvals Any Government approved Lab
DOWNLOAD TECHNICAL SPECIFICATIONS

Brochure

GAD

KMP

Spare Parts Book

MSDS

MODEL KMPHQ-5-UL90% MODEL KMPHQ-5-UL90%
Capacity 5 kg Design Ceiling Mounted
Height (Approx.) 3754 mm Diameter (Approx.) 230±10 mm
Average Discharge time 6-8 Sec. Hanging height above risk 2 m
Area Protection 1.5-2 m2 Volume Protection 2-2.5 m 3
Average % Discharge 98% Operating Temperature -30 °C to +55 °C
Service/ Test Pressure 15 / 35 bar Expelling Agent Nitrogen (UHP Grade)
Full Weight (Approx.) 7.6 kg Empty Weight (Approx.) 2.6 kg
Shipping Weight (Approx.) 7.7 kg Mounting Bracket Ceiling mounting stand
Approvals Any Government approved Lab
DOWNLOAD TECHNICAL SPECIFICATIONS

Brochure

GAD

KMP

Spare Parts Book

MSDS

MODEL KMPHQ-10-UL90% MODEL KMPHQ-10-UL90%
Capacity 10 kg Design Ceiling Mounted
Height (Approx.) 405 mm Diameter (Approx.) 300±10 mm
Average Discharge time 10-15 Sec. Hanging height above risk 2 m
Area Protection 4-5 m 2 Volume Protection 10 m3
Average % Discharge 99% Operating Temperature -30 °C to +55 °C
Service/ Test Pressure 15 / 35 bar Expelling Agent Nitrogen (UHP Grade)
Full Weight (Approx.) 14.1 kg Empty Weight (Approx.) 4.16 kg
Shipping Weight (Approx.) 14.5 kg Mounting Bracket Ceiling mounting stand
Approvals Any Government approved Lab
DOWNLOAD TECHNICAL SPECIFICATIONS

Brochure

GAD

KMP

Spare Parts Book

MSDS

MODEL KMPHQ-15-UL90% MODEL KMPHQ-15-UL90%
Capacity 15 kg Design Ceiling Mounted
Height (Approx.) 425 mm Diameter (Approx.) 400±10 mm
Average Discharge time 15-20 Sec. Hanging height above risk 2.5 m
Area Protection 5-6 m 2 Volume Protection 15 m 3
Average % Discharge 99% Operating Temperature -30 °C to +55 °C
Service/ Test Pressure 15 / 35 bar Expelling Agent Nitrogen (UHP Grade)
Full Weight (Approx.) 21.4kg Empty Weight (Approx.) 6.4 kg
Shipping Weight (Approx.) 22 kg Mounting Bracket Ceiling mounting stand
Approvals Any Government approved Lab
