CO2 Based Fire Extinguishers

CO2 Based Mobile Fire Extinguishers

KANEX CO2 type Fire Extinguishers are environmentally safe and designed to suppress the fires where Class B, C and Electrically energized fires could occur. CO2 Extinguishers are advisable to use in Indoors where wind and drafts doesn’t affect discharge and where clean medium required which doesn’t leaves residue.

Available in Kg
Buy on Amazon

Carbon Dioxide is discharged as a white cloud of “snow” which smothers a fire by eliminating oxygen. It is effective for Class B flammable liquids and is electrically non-conductive. Carbon Dioxide is a clean, non-contaminating, odorless gas.

Special Features

99.95% Pure Carbon Di Oxide gas.
Certifications: BIS Approved (IS 16018: 2012) & CE certified.
Bodies CCOE/PESO approved.
High quality enamel paint.
Brass valve of squeeze/wheel type with pressure relief discs.
Trolleys with an ability to withstand high mechanical stress.
High strength Solid Rubber wheels.
Shells are Hydro tested to 250 bar.
High pressure Wire braided Hose.
Easy as well more economical to maintain & service.
Maximum visibility during Discharge.
No Electrical Conductivity Back to the operator.
No Thermal or Static Shock.

TECHNICAL SPECIFICATIONS

MODEL KCARQ-2 MODEL KCARQ-2
Capacity 2 kg Design Nozzle
Fire Rating 1A:21B Height (Approx.) 380 mm
Diameter (Approx.) 106±10 mm Average Discharge time 14 Sec.
Average Range of throw 2 m Average % Discharge 95%
Operating Temperature -30 °C to +60 °C Service/Max. service/Test Pressure 15 / 18 / 35 bar
Expelling Agent Nitrogen (UHP Grade) Full Weight (Approx.) 3.4 kg
Empty Weight (Approx.) 1.4 kg Shipping Weight (Approx.) 3.6 kg
Packing Standard Inner- 13.75"X4.75"X4.75”
Outer (4 in 1)- 16.5"X10"X10”
Mounting Bracket Vehicle/Wall bracket
Approvals BIS
DOWNLOAD TECHNICAL SPECIFICATIONS

Brochure

Spare Parts Book

MSDS

MODEL KCARQ-4 MODEL KCARQ-4
Capacity 4 kg Design Hose & Nozzle
Fire Rating 2A:34B Height (Approx.) 490 mm
Diameter (Approx.) 140±10 mm Average Discharge time 18 Sec.
Average Range of throw 3 m Average % Discharge 95%
Operating Temperature -30 °C to +60 °C Service/Max. service/Test Pressure 15 / 18 / 35 bar
Expelling Agent Nitrogen (UHP Grade) Full Weight (Approx.) 6.6 kg
Empty Weight (Approx.) 2.6 kg Shipping Weight (Approx.) 7.0 kg
Packing Standard 2 in 1- 21"X6.75"X14.10” Mounting Bracket Wall bracket
Approvals BIS
DOWNLOAD TECHNICAL SPECIFICATIONS

Brochure

Spare Parts Book

MSDS

MODEL KCARQ-6 MODEL KCARQ-6
Capacity 6 kg Design Hose & Nozzle
Fire Rating 2A:55B Height (Approx.) 530 mm
Diameter (Approx.) 150±10 mm Average Discharge time 24 Sec.
Average Range of throw 5 m Average % Discharge 95%
Operating Temperature -30 °C to +60 °C Service/Max. service/Test Pressure 15 / 17 / 35 bar
Expelling Agent Nitrogen (UHP Grade) Full Weight (Approx.) 8.9 kg
Empty Weight (Approx.) 2.9 kg Shipping Weight (Approx.) 9.2 kg
Packing Standard 2 in 1- 21"X6.75"X14.10” Mounting Bracket Wall bracket
Approvals BIS
DOWNLOAD TECHNICAL SPECIFICATIONS

Brochure

Spare Parts Book

MSDS
