KANEX presents the modular type clean agent FE-36 gas Automatic fire extinguisher .It keeps guard, extinguishes fire quickly and efficiently when the Fire temperature reaches the temperature sensing bulb temperature. These modules are very useful especially in closed and remote places where fire could cause extensive damage if not detected and extinguished in time.
Available ranges of Temperature Sensing bulbs which sense Temperature are from 57 °C to 107 °C.
| MODEL | KMCHQ-2-FE36 | MODEL | KMCHQ-2-FE36 |
|---|---|---|---|
| Capacity | 2 kg | Design | Ceiling Mounted |
| Height (Approx.) | 380 mm | Diameter (Approx.) | 150±10 mm |
| Average Discharge time | 4-5 Sec. | Hanging height above risk | 2 m |
| Area Protection | 1-1.5 m 2 | Volume Protection | 2.5 m 3 |
| Average % Discharge | 98% | Operating Temperature | -30 °C to +55 °C |
| Service/ Test Pressure | 15 / 35 bar | Expelling Agent | Nitrogen (UHP Grade) |
| Full Weight (Approx.) | 3.6 kg | Empty Weight (Approx.) | 1.6 kg |
| Shipping Weight (Approx.) | 3.7 kg | Mounting Bracket | Ceiling mounting stand |
| Approvals | Any Government approved Lab |
| MODEL | KMCHQ-5-FE36 | MODEL | KMCHQ-5-FE36 |
|---|---|---|---|
| Capacity | 5 kg | Design | Ceiling Mounted |
| Height (Approx.) | 3754 mm | Diameter (Approx.) | 230±10 mm |
| Average Discharge time | 6-8 Sec. | Hanging height above risk | 2 m |
| Area Protection | 1.5-2 m2 | Volume Protection | 2-2.5 m 3 |
| Average % Discharge | 98% | Operating Temperature | -30 °C to +55 °C |
| Service/ Test Pressure | 15 / 35 bar | Expelling Agent | Nitrogen (UHP Grade) |
| Full Weight (Approx.) | 7.6 kg | Empty Weight (Approx.) | 2.6 kg |
| Shipping Weight (Approx.) | 7.7 kg | Mounting Bracket | Ceiling mounting stand |
| Approvals | Any Government approved Lab |
| MODEL | KMCHQ-10-FE36 | MODEL | KMCHQ-10-FE36 |
|---|---|---|---|
| Capacity | 10 kg | Design | Ceiling Mounted |
| Height (Approx.) | 405 mm | Diameter (Approx.) | 300±10 mm |
| Average Discharge time | 10-15 Sec. | Hanging height above risk | 2 m |
| Area Protection | 4-5 m 2 | Volume Protection | 10 m3 |
| Average % Discharge | 99% | Operating Temperature | -30 °C to +55 °C |
| Service/ Test Pressure | 15 / 35 bar | Expelling Agent | Nitrogen (UHP Grade) |
| Full Weight (Approx.) | 14.1 kg | Empty Weight (Approx.) | 4.16 kg |
| Shipping Weight (Approx.) | 14.5 kg | Mounting Bracket | Ceiling mounting stand |
| Approvals | Any Government approved Lab |
| MODEL | KMCHQ-15-FE36 | MODEL | KMCHQ-15-FE36 |
|---|---|---|---|
| Capacity | 15 kg | Design | Ceiling Mounted |
| Height (Approx.) | 425 mm | Diameter (Approx.) | 400±10 mm |
| Average Discharge time | 15-20 Sec. | Hanging height above risk | 2.5 m |
| Area Protection | 5-6 m 2 | Volume Protection | 15 m 3 |
| Average % Discharge | 99% | Operating Temperature | -30 °C to +55 °C |
| Service/ Test Pressure | 15 / 35 bar | Expelling Agent | Nitrogen (UHP Grade) |
| Full Weight (Approx.) | 21.4kg | Empty Weight (Approx.) | 6.4 kg |
| Shipping Weight (Approx.) | 22 kg | Mounting Bracket | Ceiling mounting stand |
| Approvals | Any Government approved Lab |
